AIPU UL2343 Multi-Conductor Unshielded Heavy Duty Industrial Control Cable

CONSTRUCTION

• Conductor Fully annealed stranded tinned copper per ASTM B33
• Insulation Premium-grade, color-coded PVC
• Sheath Premium PVC

STANDARDS

• NEC Article 800 Type CM (UL: 105°C)
• UL Style 2343 (UL: 80°C, VW-1)
• CSA Type CMG (CSA: 105°C, FT4)
• CE: Low-Voltage Directive (LVD) 2006/95/EC
• RoHS Compliant Directive 2011/65/EU
• Vertical Tray Cable Flame Test per UL 1581 and IEEE 383 (70,000 BTU)

CHARACTERISTICS

• Voltage Rating 300V
• Testing Voltage 2000kV
• Operating temperature range -30°C to +105°C (Type CM) -30°C to +80°C (AWM)
• Minimum Bending Radius Fixed 4 x cable Ø / mobile use 10 x cable Ø

APPLICATION

• Advanced signal transmission in controlled environments
• Medical instrumentation and equipment
• Consumer electronic peripherals
• Industrial process control systems
• Suitable for EIA RS-232 applications

DIMENSION
