  • Aipu CAT6 Cable Factory Sell in Bulk Cat.6 UTP Cable LAN Cable UTP Cable Factory

    Aipu CAT6 Cable Factory Sell in Bulk Cat.6 UTP Cable LAN Cable UTP Cable Factory

    Description
    •  Provide 250MHz bandwidth in 100m, typical speed rate:1000Mbps
    • Widely used for horizontal cabling in working area and LAN indoor
    • High grade OFC (oxygen free copper) conductor, 4pairs separately design by crossed PE spline, reliable transmission performance,meets or exceeds standard, provide plentiful redundancy for system link, fast and convenient installation
    inquirydetail
  • Aipu 309Y to BS6500 Green/Yellow, Brown, Black Grey & Blue 4 Cores Industrial Cable Light Wire

    Aipu 309Y to BS6500 Green/Yellow, Brown, Black Grey & Blue 4 Cores Industrial Cable Light Wire

    Application
    For use on small appliances with low mechanical stress and for connection for
    light household appliances to 90°C.
    Constructions
    1. Conductor: Class 5 Oxygen Free Copper
    2. Insulation: PVC
    3. Identification:
                            2 Cores: Blue & Brown
                            3 Core: Green/Yellow, Blue & Brown
                            4 Core: Green/Yellow, Brown, Black & Grey
                            5 Core: Green/Yellow, Brown, Black Grey & Blue
    4. Sheath: PVC
    inquirydetail
  • Aipu 318Y/B to BS6500 Cable Oxygen Free Copper Cable PVC LSZH Cable Oem Cable Factory 300/500V Rated Voltage

    Aipu 318Y/B to BS6500 Cable Oxygen Free Copper Cable PVC LSZH Cable Oem Cable Factory 300/500V Rated Voltage

    Application
    For use on small appliances with low mechanical stress and for connection for
    light household appliances
    Constructions
    1. Conductor: Class 5 Oxygen Free Copper
    2. Insulation: PVC, LSZH
    3. Identification:
                            2 Cores: Blue & Brown
                            3 Core: Green/Yellow, Blue & Brown
                            4 Core: Green/Yellow, Brown, Black & Grey
                            5 Core: Green/Yellow, Brown, Black Grey & Blue
    4. Sheath: PVC, LSZH
    inquirydetail
  • Aipu 218Y/B to BS6500 Light Coble Household Cable H03VVH2-F 2×0.5/H03VVH2-F 2×0.75 3 Cores Appliances Cable

    Aipu 218Y/B to BS6500 Light Coble Household Cable H03VVH2-F 2×0.5/H03VVH2-F 2×0.75 3 Cores Appliances Cable

    Application
    For use on small appliances with low mechanical stress and for connection for
    light household appliances.
    Constructions
    1. Conductor: Class 5 Oxygen Free Copper
    2. Insulation: PVC, LSZH
    3. Identification:
                2 Cores: Blue & Brown
               3 Core: Green/Yellow, Blue & Brown
               4 Core: Green/Yellow, Brown, Black & Grey
               5 Core: Green/Yellow, Blue & Brown & Black
    4. Sheath: PVC, LSZH
    inquirydetail
  • Aipu Foundation Fieldbus Type A Cable 18~14 AWG 2 Cores Yellow Color Control Automation Industry Cable

    Aipu Foundation Fieldbus Type A Cable 18~14 AWG 2 Cores Yellow Color Control Automation Industry Cable

    Application
    For process control automation industry and quick connection of the cable to the
    respective plugs in the field area.
    Constructions
    1. Conductor: Stranded Tinned Copper Wire
    2. Insulation: Polyolefin
    3. Identification: Blue, Orange
    4. Screen: Individual & Overall Screen
    5. Sheath: PVC/LSZH
    6. Sheath: Yellow

    » Installation Temperature: Above 0°C
    » Operating Temperature: -15°C ~ 70°C
    inquirydetail
  • Aipu Profibus Dp Cable 2 Cores Purple Color Tinned Copper Wire Braided Screen Profibus Cable

    Aipu Profibus Dp Cable 2 Cores Purple Color Tinned Copper Wire Braided Screen Profibus Cable

    Application
    For deliver time-critical communication between process automation systems
    and distributed peripherals. This cable is usually referred as S iemens profibus.
    Constructions
    1. Conductor: Solid Oxygen Free Copper (Class 1)
    2. Insulation: S-FPE
    3. Identification: Red, Green
    4. Bedding: PVC
    5. Screen:
       1. Aluminium/Polyester Tape
       2. Tinned Copper Wire Braided (60%)
    6. Sheath: PVC/LSZH/PE
    7. Sheath: Violet
    inquirydetail
  • Aipu Multi-Core Screened Sound Cable 7 Cores Audio Security Safety Control Instrumentation Cable

    Aipu Multi-Core Screened Sound Cable 7 Cores Audio Security Safety Control Instrumentation Cable

    Application
    For BMS, Sound, Audio, Security, Safety, Control and Instrumentation application
    indoor & outdoor.
    Constructions
    1. Conductor: Stranded Tinned Copper Wire
    2. Insulation: Polyolefin, PVC
    3. Cabling: Cores laying-up
    4. Screened: Individually Screened (Optional)
    Al-PET tape with Tinned Copper Drain Wire
    Tinned Copper Braided
    Tinned Copper Spiral
    5. Sheath: PVC/LSZH
    inquirydetail
  • Aipu BMS Control Cable Audio BS EN 60228 50290 Sound Cable 4 Pairs 8 Cores Twist Pair Cable

    Aipu BMS Control Cable Audio BS EN 60228 50290 Sound Cable 4 Pairs 8 Cores Twist Pair Cable

    Application
    For BMS, Sound, Audio, Security, Safety, Control and Instrumentation application
    indoor & outdoor.
    Constructions
    1. Conductor: Stranded Tinned Copper Wire
    2. Insulation: Polyolefin, PVC
    3. Cabling: Twist Pairs laying-up
    4. Screened: Individually Screened (Optional)
    Al-PET tape with Tinned Copper Drain Wire
    5. Sheath: PVC/LSZH
    inquirydetail
  • Aipu Speaker Cable Indoor Outdoor Stranded Oxygen Free Copper Twist Pairs 2 Cores

    Aipu Speaker Cable Indoor Outdoor Stranded Oxygen Free Copper Twist Pairs 2 Cores

    Application

    For loudspeaker application indoor & outdoor.

    Constructions
    1. Conductor: Stranded Oxygen Free Copper
    2. Insulation: Polyolefin
    3. Cabling: Cores laying-up
    4. Sheath: PVC/LSZH

    »» Installation Temperature: Above 0°C
    »»Operating Temperature: -15°C ~ 70°C

    inquirydetail
  • Aipu Digital Audio Transmission Cable PVC/LSZH Individually Screened Al-PET Tape with Tinned Copper Drain Wire Al-PET Tape & Tinned Copper Braided

    Aipu Digital Audio Transmission Cable PVC/LSZH Individually Screened Al-PET Tape with Tinned Copper Drain Wire Al-PET Tape & Tinned Copper Braided

    Application

    For digital audio transmission.

    Constructions
    1. Conductor: Stranded Oxygen Free Copper
    2. Insulation: S-FPE
    3. Cabling: Twist Pairs laying-up
    4. Screened: Individually Screened (Optional)
    Al-PET tape with Tinned Copper Drain Wire
    Al-PET Tape & Tinned Copper Braided
    5. Sheath: PVC/LSZH

    »» Insulation cores are in blue and white color with number printed.

    »» Installation Temperature: Above 0°C
    »»Operating Temperature: -15°C ~ 65°C

    Reference Standards
    »» BS EN 60228
    »» BS EN 50290
    »» RoHS Directives

    Electrical Performance

    Velocity of Propagation           76%
    Impedance                                0.1-6MHz 110 Ω ± 15 Ω
    Test Voltage                               1.0 KVdc
    Conductor DCR                       134 Ω/km (Max. @ 20°C) for 26AWG
                                                        89.0 Ω/km (Max. @ 20°C) for 24AWG
                                                       56.0 Ω/km (Max. @ 20°C) for 22AWG

    Contact us to get product catalog

    微信图片_20230612165757 微信图片_202306121657571 微信图片_202306121657572 微信图片_202306121657573 微信图片_202306121657574 微信图片_202306121657575 微信图片_202306121657576

    inquirydetail
  • Aipu Analog Audio Transmission Cable 4 Pairs 8 Cores Twist Pairs Al-PET Tape with Tinned Copper Drain Wire Al-PET Tape & Tinned Copper Braided

    Aipu Analog Audio Transmission Cable 4 Pairs 8 Cores Twist Pairs Al-PET Tape with Tinned Copper Drain Wire Al-PET Tape & Tinned Copper Braided

    Application

    For analog audio transmission.

    Constructions
    1. Conductor: Stranded Oxygen Free Copper
    2. Insulation: S-PE
    3. Cabling: Twist Pairs laying-up
    4. Screened: Individually Screened (Optional)
                         Al-PET tape with Tinned Copper Drain Wire
                         Al-PET Tape & Tinned Copper Braided
    5. Sheath: PVC/LSZH

    »» Insulation cores are in blue and white color with number printed.

    »» Installation Temperature: Above 0°C
    »»Operating Temperature: -15°C ~ 65°C



    inquirydetail
  • Aipu RS-422 Computer Cable Stranded Tinned Copper Wire Twist Pairs 4 Pairs 8 Cores Individually Al-PET Tape PVC LSZH

    Aipu RS-422 Computer Cable Stranded Tinned Copper Wire Twist Pairs 4 Pairs 8 Cores Individually Al-PET Tape PVC LSZH

    Application
    For EIA RS 422 applications, used as computer cables.

    Constructions
    1. Conductor: Stranded Tinned Copper Wire
    2. Insulation: S-FPE
    3. Cabling: Twist Pairs laying-up
    4. Screened: Individually Al-PET tape with Tinned Copper Drain Wire
    5. Sheath: PVC/LSZH

    »» Installation Temperature: Above 0°C
    »»Operating Temperature: -15°C ~ 65°C



    inquirydetail
